ParameterSettingThesettingsoftheLinearGagethatyouwilluse,thedisplayoftheCounter,andexternaloutputarespecifiedbysettingparameters.Setparametersbeforeyoubeginmeasuring.■ProcedureforSettingParametersParametersaresetinParametermode.Asanexample,thissectionexplainstheoperationalprocedureforsettingtheCounterdirection(thedirectioninwhichthespindleofaLinearGageispressedin)totheminus(-)direction.1Connectthepower.»TheCounterentersthestand-bystate.2Pressandhold[Fn],andthenpress[P.SET].»TheCounterentersParametermode.(Thesetvalueofparameternumber00willblink.)ParameternumberSetvalue3Press[P.SET]oncetosetthevalueto1(parametersetting).»Parameterscannowbemodified.(Thesetvalueremainsblinking.)ParameternumberSetvalueTipsIfthesettingvalueis0,youcanviewtheparametervalues,butyoucannotchangethem.4Repeatedlypress[Fn]toadvancetheparameternumberto11.»Thecurrentvalueofparameternumber11willblink.(Parameternumber11setstheParameternumberSetvalueCounterdirection.)5Repeatedlypress[P.SET]tosetthevalueto1("-"direction).»Thevaluewillbesetto1.(TheCounterdirectionwillbesettothe"-"direction.)ParameternumberSetvalue6Pressandhold[Fn],andthenpress[P.SET].»TheCounterwillreturntothestand-bystate.1-46
| <
|
> |
>>
